ARTICULATED CRANES 3 TON

ARTICULATED CRANES 3 TON
ARTICULATED CRANES 3 TON
ARTICULATED CRANES 3 TON
ARTICULATED CRANES 3 TON
ARTICULATED CRANES 3 TON

ARTICULATED CRANES 3 TON

  • NH00391
  • Lifting moment: 6,58 tm
  • Max. vert. reach: 12,90 m
  • Slewing angle: 387º
  • Slewing time: 15 s/180º
  • Rotating hook, capacity: 5,4 ton
  • Crane w/o stab: 1180 kg
  • Standard colour: Vàng RAL 1023
  • Oil tank capacity: 35 l
  • Working pressure: 245 bar
  • Dim: 2250x1980x600 mm
Add product to cart
Order
Rent

MAIN SPECIFICATION

  • Lifting moment: 6,58 tm
  • Max. vert. reach: 12,90 m
  • Slewing angle: 387º
  • Slewing time: 15 s/180º
  • Rotating hook, capacity: 5,4 ton
  • Crane w/o stab: 1180 kg
  • Standard colour: Vàng RAL 1023
  • Oil tank capacity: 35 l
  • Working pressure: 245 bar
  • Dim: 2250x1980x600 mm

APPICATION

This range of basic articulated cranes is known for its extensive versatility and user-friendliness. The HB line has articulated cranes in the 3 tm to 70 tm class.

Contact information

HATRINO CO.,LTD

Adress: No 01, Alley 17/199, Ho Tung Mau  Rd, Nam Tu Liem  Dist., Ha Noi City, Viet Nam.

Center service: Minh kha, Binh minh, Thanh Oai Dist, Ha Noi City.

Cell phone: 84 90 177 2222

E-mail: hatrino.ltd@gmail.com
