• Lifting moment: 54,4 tm
• Max. vert. reach : 16,3 m
• Slewing angle : 420º
• Slewing time: 18 s/180º
• Working pressure: 290 bar
• Crane w/o stab: 5100 kg
• Weight stab: 900 kg
• Oil tank capacity : 250 l
• Dim : 2550 x2420x1456 mm
• Truck min GVW: 24 ton

• Lifting moment: 45,5 tm
• Max. vert. reach : 11,6 m
• Slewing angle : 385º
• Slewing time: 20 s/180º
• Working pressure: 270 bar
• Crane w/o stab: 3885 kg
• Weight stab: 740kg
• Oil tank capacity : 250 l
• Dim : 2550 x2495x1280 mm
• Truck min GVW: 22 ton

• Lifting moment: 32,8 tm
• Max. vert. reach : 11,6 m
• Slewing angle : 380º
• Slewing time: 20 s/180º
• Working pressure: 300 bar
• Crane w/o stab: 3165 kg
• Oil tank capacity : 160 l
• Dim : 2550 x2490x1175 mm
• Truck min GVW: 22 ton

• Lifting moment: 25,1 tm
• Max. vert. reacht : 19,3 m
• Slewing angle : 400º
• Slewing time: 20 s/180º
• Rotating hook, capacity: 11,5 ton
• Crane w/o stab: 3735 kg
• Standard colour/: Vàng RAL 1023
• Oil tank capacity : 160 l
• Working pressure: 290 bar
• Dim: (2540x2320x1200) mm

• Lifting moment: 19,6 tm
• Max. vert. reach : 19,8 m
• Slewing angle : 387º
• Slewing time: 17 s/180º
• Rotating hook, capacity: 15 ton
• Crane w/o stab: 2900 kg
• Standard colour: Vàng RAL 1023
• Oil tank capacity : 130 l
• Working pressure: 300 bar
• Dim : 2495x2295x1000 mm

• Lifting moment: 15,8 tm
• Max. vert. reacht : 19,8 m
• Slewing angle : 387º
• Slewing time: 17 s/180º
• Rotating hook, capacity: 8,0 ton
• Crane w/o stab: 2620 kg
• Standard colour: Vàng RAL 1023
• Oil tank capacity : 130 L
• Working pressure: 310 bar
• Dim : 2495x2395x1000 mm

• Lifting moment: 13,9 tm
• Max. vert. reacht : 18,8 m
• Slewing angle : 380º
• Slewing time: 17 s/180º
• Rotating hook, capacity: 8,0 ton
• Crane w/o stab: 2120 kg
• Standard colour: Vàng RAL 1023
• Oil tank capacity : 100 l
• Working pressure: 290 bar
• Dim: 2490x2340x1030 mm

• Lifting moment: 6,58 tm
• Max. vert. reach: 12,90 m
• Slewing angle: 387º
• Slewing time: 15 s/180º
• Rotating hook, capacity: 5,4 ton
• Crane w/o stab: 1180 kg
• Standard colour: Vàng RAL 1023
• Oil tank capacity: 35 l
• Working pressure: 245 bar
• Dim: 2250x1980x600 mm

• Lifting moment: 2,61 tm
• Max. vert. reach : 7,38m
• Slewing angle : 370º
• Slewing time: 10 s/180º
• Rotating hook, capacity: 2,0 ton
• Crane w/o stab: 450 kg
• Standard colour: Vàng RAL 1023
• Oil tank capacity : 25 l
• Working pressure: 175 bar
• Dim : 2000x1590x490 mm

Marine Crane has a wide range of foldable knuckle and telescopic boom cranes, for low deck space occupation and very compact recovering.
