COMPACT TELESCOPIC BOOM 1,5 TON

COMPACT TELESCOPIC BOOM 1,5 TON

Code: NH00388

Lifting moment: 2,61 tm
Max. vert. reach : 7,38m
Slewing angle : 370º
Slewing time: 10 s/180º
Rotating hook, capacity: 2,0 ton
Crane w/o stab: 450 kg
Standard colour: Vàng RAL 1023
Oil tank capacity : 25 l
Working pressure: 175 bar
Dim : 2000x1590x490 mm

Add product to cart

Description
Highlight product
Condition

MAIN SPECIFICATION

Lifting moment: 2,61 tm
Max. vert. reach : 7,38m
Slewing angle : 370º
Slewing time: 10 s/180º
Rotating hook, capacity: 2,0 ton
Crane w/o stab: 450 kg
Standard colour: Vàng RAL 1023
Oil tank capacity : 25 l
Working pressure: 175 bar
Dim : 2000x1590x490 mm

APPLICATION

This line of telescopic cranes is ideal for applications that require a compact, light and easy to operate solution. Thanks to their extremely compact dimension all our cranes in the HA series are projected to be mounted on small equipment such as: cat trailer, tracked vehicle, pickup, small trucks and stationary mounting.

Contact information

HATRINO CO.,LTD

Adress: No 01, Alley 17/199, Ho Tung Mau Rd, Nam Tu Liem Dist., Ha Noi City Viet Nam.

Center service: Minh kha, Binh minh, Thanh Oai Dist, Ha Noi City.

Cell phone: 84 90 177 2222

E-mail: hatrino.ltd@gmail.com
