1. Home
  2. ARTICULATED CRANES 8TON

ARTICULATED CRANES 8TON

ARTICULATED CRANES 8TON
ARTICULATED CRANES 8TON
ARTICULATED CRANES 8TON
ARTICULATED CRANES 8TON

ARTICULATED CRANES 8TON

  • NH00395
  • Lifting moment: 19,6 tm
  • Max. vert. reach : 19,8 m
  • Slewing angle : 387º
  • Slewing time: 17 s/180º
  • Rotating hook, capacity: 15 ton
  • Crane w/o stab: 2900 kg
  • Standard colour: Vàng RAL 1023
  • Oil tank capacity : 130 l
  • Working pressure: 300 bar
  • Dim : 2495x2295x1000 mm
Add product to cart
Order
Rent

MAIN SPECIFICATION

  • Lifting moment: 19,6 tm
  • Max. vert. reach : 19,8 m
  • Slewing angle : 387º
  • Slewing time: 17 s/180º
  • Rotating hook, capacity: 15 ton
  • Crane w/o stab: 2900 kg
  • Standard colour: Vàng RAL 1023
  • Oil tank capacity : 130 l
  • Working pressure: 300 bar
  • Dim : 2495x2295x1000 mm

APPLICATION

This range of basic articulated cranes is known for its extensive versatility and user-friendliness. The HB line has articulated cranes in the 3 tm to 70 tm class.
