Main specification.

Working height: 16.6m

Platform height: 14.6m

Horizontal Reach: 11,3m

Loading capacity: 250kg

Manbasket dimension:1400x700x1100 mm

Power:  Engine

GVW Min: 3,5 ton

Overview

• 400° Turret rotation
• Smooth proportional controls with acceleration and deceleration ramps
• CAN BUS electronic management system
• Ground control station with 7m cable wired console
• Diagnostic display on board
• Automatic engine rpm management
• Engine start/stop control from the basket and the ground
• Anti-slip aluminum deck
• outreach and height max values and repeatability can change within ± 3% due to manufacturing variation and working condition.
